0.9 m wide glass door cabinet E7 ATLANTA

PRODUCTS

1. Operating temperature is -1~5℃

2. Display fresh, meat, dairy products and beverages

3. Length: 1500mm(two doors), 2200mm (three doors), 3000mm (four doors), 3750mm (five doors)

4. It can be spliced arbitrarily

5. Color can be customized

6. Electric heating anti-dew glass door

★The different temperature ranges can be set according to the different demands： -1~5℃ for fresh foods, fresh meat, milk, beverage and so on; -18~-22℃ for frozen foods, ice cream, sea foods, etc.
★4 basic length specifications: 1550mm(2 doors), 2250mm( 3doors), 3000mm(4 doors) and 3750mm(5 doors). Can be jointed together freely.
★The shunt structure of cooling air is adopted to achieve uniform cooling effect and to eliminate the cooling dead ends.
★Glass door with electrical heating and anti-condensation reduces power consumption.
★Glass door can close automatically.
★Multi-layer grid shelves can be combined freely with angle adjustable to augment display effects.
★Save 60% space compared to same volume island freezer.
★Save 50% energy compared to open type, Low running cost, invest one-off, benefit lifelong.

NO	Product Type	LWH(mm)	Temp.	Net Volume(L)
NO	Product Type	LWH(mm)	Temp.	Net Volume(L)
	E7 ATLANTA (Frozen)H20
1	BD-E7YT-F1520-01	15009322085	L1（≤-15℃）	1035
2	BD-E7YT-F2220-01	22509322085		1553
3	BD-E7YT-F3020-01	30009322085		2070
4	BD-E7YT-F3720-01	37509322085		2650
	E7 ATLANTA (Frozen) H20
1	BD-E7YT-F1520-E1	15009322085	L1（≤-15℃）	1035
2	BD-E7YT-F2220-E1	22509322085		1553
3	BD-E7YT-F3020-E1	30009322085		2070
4	BD-E7YT-F3720-E1	37509322085		2650
	E7 ATLANTA (Refrigerator)H20
1	BZ-E7YT-F1520-01	15009322085	M1(-1～5℃)	1035
2	BZ-E7YT-F2220-01	22509322085		1553
3	BZ-E7YT-F3020-01	30009322085		2070
4	BZ-E7YT-F3720-01	37509322085		2650
	E7 ATLANTA (Refrigerator)H20
1	BZ-E7YT-F1520-E1	15009322085	M1(-1～5℃)	1035
2	BZ-E7YT-F2220-E1	22509322085		1553
3	BZ-E7YT-F3020-E1	30009322085		2070
4	BZ-E7YT-F3720-E1	37509322085		2650
	E7 ATLANTA (Refrigerator)H20
1	BD-E7YT-F3720-03	37509322085	L1（≤-15℃）	2650
	E7 ATLANTA (Frozen)H22
1	BD-E7YT-F1522-01	15009322285	L1（≤-15℃）	1200
2	BD-E7YT-F2222-01	22509322285		1800
3	BD-E7YT-F3022-01	30009322285		2400
4	BD-E7YT-F3722-01	37509322285		3000
	E7 ATLANTA (Frozen)H22
1	BD-E7YT-F1522-E1	15009322285	L1（≤-15℃）	1200
2	BD-E7YT-F2222-E1	22509322285		1800
3	BD-E7YT-F3022-E1	30009322285		2400
4	BD-E7YT-F3722-E1	37509322285		3000
	E7 ATLANTA (Refrigerator)H22
1	BZ-E7YT-F1522-01	15009322285	M1(-1～5℃)	1200
2	BZ-E7YT-F2222-01	22509322285		1800
3	BZ-E7YT-F3022-01	30009322285		2400
4	BZ-E7YT-F3722-01	37509322285		3000
	E7 ATLANTA (Refrigerator)H22
1	BZ-E7YT-F1522-E1	15009322285	M1(-1～5℃)	1200
2	BZ-E7YT-F2222-E1	22509322285		1800
3	BZ-E7YT-F3022-E1	30009322285		2400
4	BZ-E7YT-F3722-E1	37509322285		3000
	E7 ATLANTA (Refrigerator)H22
1	BD-E7YT-F3022-03	30009322285	L1（≤-15℃）	2400
2	BD-E7YT-F3722-03	37509322285	L1（≤-15℃）	3000
