Refrigerated unit E7 austin

1. Bottom operating temperature <=-18℃

2. Top operating temperature is -1~7℃

3. Meat products, sea products, ice cream, quick-frozen dumplings, etc. are displayed at the bottom.

4. Drinks, dairy products and vacuum-packed cooked food are displayed on the top

5. The cabinet length is 1875mm, 2500mm and 3750mm



  • ★≤-18℃ of bottom cabinet for frozen foods, ice cream, sea foods, etc. -1~7℃ of top cabinet for beverage, milk and cooked food.

    ★3 basic length specifications: 1875mm, 2500mm and 3750mm.Can be jointed together freely to suit your length requirements.




  • ★Integration cooling and frozen two types of cabinets in one achieve different use requirements. Large Effective volume.

    ★Anti-reflective sliding glass-door for bottom freezer can reduce cooling consumption and save energy.

    ★Ultra-thin and large area high-efficient evaporator rapidly cool fast.

    ★Spare parts with anti-corrosion anti-rust treatment.

    ★New green environment-friendly polyurethane foaming process with good insulation performance.


  • 20190725164931150.jpg@!w1200

    20190725164930999.jpg@!w1200
    20190725164931165.jpg@!w1200

    20190725164931498.jpg@!w1200

    20190725164930135.jpg@!w1200
    20190725164931349.jpg@!w1200

    20190725164931467.jpg@!w1200

    20190725164931136.jpg@!w1200

  • 20190725173352703.jpg



  • Product Type

    English Name

    L*W*H(mm)

    Temp.

    Net Volume(L)

    1

    BD-E7AS-F12235T-01

    E7 AUSTIN

    1250*1095*2280

    —18~-22℃-1~7℃

    773

    2

    BD-E7AS-F18235T-01

    1875*1095*2280

    1159

    3

    BD-E7AS-F22235T-01

    2200*1095*2280

    1360

    4

    BD-E7AS-F25235T-01

    2500*1095*2280

    1546

    5

    BD-E7AS-F37235T-01

    3750*1095*2280

    2319
